- Type:
-
Fixed wing
- Use:
-
Drone/UAV
- Condition:
-
New
- Size:
-
Large Size
- Place of Origin:
-
Beijing, China
- Model Number:
-
HC-132
- Brand Name:
-
Honeycomb CHINA
- Body length:
-
3250mm
- Maximum take-off weight:
-
9kg
- Max payload:
-
20kg
- Cruising speed:
-
100 ~ 120 km/h
- Max Altitude:
-
4000m (Above sea level)
- Endurance:
-
Up to 5.5h
- Power plant:
-
Gasoline engine
- Flight mode:
-
Manual / Auto
- Control radius:
-
≥10km (no obstacles)
- Wind resistance level:
-
level 5
- Supply Ability:
- 5 Unit/Units per Month
- Packaging Details
- We offer Industrial Level Special for Drones Packaging.
- Port
- Beijing
- Picture Example:
-
- Lead Time :
-
Quantity(Units) 1 - 5 >5 Est. Time(days) 30 To be negotiated
Category | Specification | Parameter |
Flight System & Powerplant | Body Length | 3251mm |
Wingspan | 5270mm | |
Payload | Customization | |
Manufacture material | Carbon fiber | |
Empty weight | 55kg | |
Max take-off weight (sea level) | 120kg | |
Standard payload | 40.0kg | |
Max payload | 50.0kg | |
Standard propeller | 36×12 inch | |
Cruising speed | 100 ~ 130km/h | |
Max flight speed | 160km/h | |
Max Altitude | 5000m (Above sea level) | |
Endurance | Up to 8h | |
Max Payload | ||
Powerplant | Gasoline engine | |
Engine | 3W275 Gasoline engine | |
Electric motor | ||
Electric speed controller (ESC) | 60A brushless ESC | |
Fuel tank capacity | 50L | |
Specific fuel consumption (SFC) | 5~10L/h | |
Assembly way | Detachable | |
Flight Control System | Attitude angle navigation accuracy | Static 0.5˚ / Dynamic 1˚ |
Position navigation accuracy | Horizontal 10cm / Vertical 50cm | |
Positioning accuracy | Normal 10cm / Differential 1cm | |
Attitude control accuracy | ±1˚ | |
Direction control accuracy | ±2˚ | |
Position control accuracy | ±10cm | |
Positioning algorithm | RTK GNSS/GNSS+INS | |
Operating temperature range | -20˚C ~ 40˚C | |
Flight mode | Manual / Auto | |
Emergency measure | Out-of-control return, low voltage return, fault alarm | |
Link system | Control radius | ≥120km (no obstacles) |
Video Output resolution | 1080P@60fps | |
Operational environment | Wind resistance level | Level 5 |
Operating temperature | -20˚C ~ 40˚C | |
Rain resistance level | IP54 | |
Aircraft Logistics | Control radius | 5-10km (no obstacles) |
Video Output resolution | 1080P@60fps | |
Operational environment | Wind resistance level | Level 5 |
Operating temperature | -20˚C ~ 40˚C | |
Remote Controller | Rain resistance level | IP54 |
Aircraft Logistics | Unfold, fold time | ≤10min |
Fuel | 92 gasoline with engine oil 25:1 mixed fuel | |
Remote Controller | Model | FUTABA T8FG |
Work frequency | 2.4 GHz | |
Max signal effective distance (no interference, no occlusion) | 2km |
Training Objectives
In order to make our clients involved in the project, fully understand all the equipment provided by us and enhance the operational skills of the equipment, we will be responsible for organizing comprehensive and high-quality training for equipment operations and management maintenance personnel. In addition to providing the users with technical instructions, operation instructions and relevant documents of the whole equipment.
Click here to get details.
Maintenance support
Q: How will you deliver the goods to me?
A: Alibaba will offer you a PI (Proforma Invoice).
Q. Do you test your aircrafts before delivery?
A: Yes, we have 100% test before delivery, and we will offer you a test report.
Q: What is your warranty and after-services?
A: Our warranty is 12 months after you received the goods. We will pay high attention to after-sales service. Click here to get the details.
Q: Can you provide OEM services?
A: We can negotiate for OEM services.
Q: What is the lead time? (How long will it take to prepare my order?)
A: The exact time will be based on quantity, your specific requirements and area of delivery. (normally 10 to 90 days). You can directly contact us and we will give you exact timing.
Q: Do you accept the order which requires some modifications on your drones or customized design?
A: Yes, we do
Q: Can you offer some other payloads meeting my requirements?
A: Yes, we can. We can offer solutions of the payloads based on your specific requirements. You can also buy our flight platform and integrate the payload by yourself.
Q: Is there any tracking number for my order?
A: Yes, we ship every order with unique Tracking number, and you can view the shipment status on corresponding website.
